Large engineering eccentric hemispherical valve or plug valve

Top Entry Cast Steel Trunnion Ball ValveFeatures1. Top Entry Cast Steel Body2. Available with Bi-directional Sealed3. Trunnion Mounted Ball Structure4. Blow-out Proof Stem5. Anti-static Design6. Fire-safe Design7. Double Block & Bleed8. Full Port / Reduced Port9. Various Connection End Standard Available10. Inner Stem Seals

Featured Products


Big Project Eccentric Semi-Ball Valve or Plug Valve
Big Project Eccentric Semi-Ball Valve or Plug Valve

Top Entry Cast Steel Trunnion Ball Valve

Features


1. Top Entry Cast Steel Body
2. Available with Bi-directional Sealed
3. Trunnion Mounted Ball Structure
4. Blow-out Proof Stem
5. Anti-static Design
6. Fire-safe Design
7. Double Block & Bleed
8. Full Port / Reduced Port
9. Various Connection End Standard Available
10. Inner Stem Seals Provide a Reliable Combination of Bearing and Pressurized Stem Seal
11. Assisted by Line Pressure, Provides a Constant Mechanical Force on Ball Against Seat to Maintain Seal
12. Available with Manual Operation or Automized with Actuators.


Specifications

1). Size: 2"-24"
2). Material: Stainless Steel, CF8, CF8M, CF3, CF3M, 304, 316, 304L, 316L, WCB, LCC
3). Seat Material: Co-based Alloy, Ni-base Alloy, Tungsten Carbide and Chromium Carbide
4). Pressure: PN16-PN110, 150LB-600LB
5). Availably Connection: Flanged, SW, BW, Clamped
6). Port: Full Port / Reduced Port
7). Operation: Manual, Pneumatic, Electric
8). Suitable Medium: Heavy Particle Media, Corrosive Media
9). Applications: Petrochemical Industry, Oil Fields, Metallurgy, Coal Chemical Industry, Power Station,
Solar Energy Industry, Paper Making Industry, Pharmacy Industry, Mining Industry etc
10). Design Standard: API 6D
11). Inspection and Testing: API 598


Producs Show

Contact
Thanks for your visiting.
If you have any questions about our products or company, please do not hesitate to contact us.
Brand:HUIZHENG
Applicable Media:Heavy Particle Media, Corrosive Media
Normal Pressure:PN16-PN110, 150LB-600LB
Certification:CE/API/DNV/FDA/ISO9001-2008
Sample Testing:One Sample for free( Under $10),Freight Collect
Packing:Plastic Bag, Carton & Plywood Case/According to customers' requirement.
Payment: T/T, L/C, D/P, Western Union, Paypal
Port: NINGBO/SHANGHAI, Customers' Request
Delivery Time:Within 35days after receiving T/T deposit Payment
Term of Delivery:FOB/CNF/CIF, Customers' Request
