Flanged ball valve with fireproof design/150lb/300lb stainless steel 2PC flanged ball valve

ANSI 150lb Full Bore cast Steel Flange Ball ValveProduct DescriptionProduct Specification: 1.      Size: 1/2\'\'-8\'\'2.      Pressure Rating: PN16~PN403.      Material: GS-C25N 1.0619, 1.4308.1.4408 etc.4.

Featured Products

ANSI 150lb Full Bore cast Steel Flange Ball Valve
Product Description
Product Specification:
1.      Size: 1/2''-8''
2.      Pressure Rating: PN16~PN40
3.      Material: GS-C25N 1.0619, 1.4308.1.4408 etc.
4.      Suitable Temperature: -196ºC~450ºC( Different temperature choose different materials).
5.      Suitable Medium: Water, Steam, Oil and natural gas etc.

Technical Specification:
1.      Design & Manufacture standard: DIN 3357.
2.      Pressure & Temperature standard: DIN 3230.
3.      Face to face dimension standard: DIN 3202.
4.      Flange standard: DIN2543-2545/DIN 2501.
5.      Test & Inspect standard: DIN 2401.

Product Feature:
1.      Floating ball, full bore or reduce bore.
2.      ISO5211 mounting pad for option.
3.      Blow-out proof stem design.
4.      PTFE/RPTFE seat seal( Seat seal material could be decided by customer's request or according to valve's medium & temp. condition).
5.      Fire-proof and anti-static design if need.
6.      Operation: Hand wheel, Worm wheel, Pneumatic actuator & Electric Actuator.

Product NameSS304 Full Bore ANSI 300LB Stainless Steel Flange Ball Valve
1. MaterialA351 CF8M/CF8/CF3, A216 WCB, A352 LCB/LCB
2. Size1/2''~8'' ( DN15~DN200)
3.CertificateISO9001 & CE
4. PortFull Port
5. Working Pressure150LB-300LB
6. Connection EndsFlange(RF/RTJ)
7. Working Temp.-196ºC~450ºC(Different temperature choose different materials)
8. Suitable MediumWater, Steam, Oil and natural gas etc.
9. SealPTFE, RPTFE, PPL
10. LockingOption
11. Inspection & TestingAccording to DIN2401
Shipment
Delivery Time15~20 Days
PackageStandard Exporting Plywood Case
Shipping PortNingbo/Shanghai, China
Shipping TermsExw, FOB, CFR, CIF, etc.
Payment TermsT/T, Western Union, PayPal, etc.
 30% prepayment, 70% balance paid before shipping or against copy of BL
Warranty18 Months after leaving factory
AdvantageOEM/ODM is applicable
OthersWe also manufacture Flange Ball Valve, Gate Valve, Globe Valve, Check Valve, Butterfly Valve & Y Strainer
Flanged Ball Valve with Fire Safe Design/150lb/300lb Stainless Steel 2PC Flange Ball Valve
Flanged Ball Valve with Fire Safe Design/150lb/300lb Stainless Steel 2PC Flange Ball Valve
Flanged Ball Valve with Fire Safe Design/150lb/300lb Stainless Steel 2PC Flange Ball Valve
Flanged Ball Valve with Fire Safe Design/150lb/300lb Stainless Steel 2PC Flange Ball Valve
Flanged Ball Valve with Fire Safe Design/150lb/300lb Stainless Steel 2PC Flange Ball ValveFlanged Ball Valve with Fire Safe Design/150lb/300lb Stainless Steel 2PC Flange Ball Valve
Flanged Ball Valve with Fire Safe Design/150lb/300lb Stainless Steel 2PC Flange Ball Valve
 RFQ
Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time?

A: Generally it is 10-15 days if the goods are in stock. or it is 30 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
