| Technical Data |
| Design Standard | API6D, BS1868, DIN3356,EN10739 |
| Body Material | Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel.etc. |
| NACE MR-01-75/NACE MR-01-03 Special Requirements |
| Pressures range | ANSI 150 ~ANSI 2500 ,PN10~PN420 |
| Size range | DN50(2") ~DN1200 (48") |
| Face to Face | ANSI B16.10,EN 558,DIN3202 |
| Flanged RF, FF, RTJ Ends | ASME B16.5 ≤ DN600 (24") ASME B16.47 A ≥ DN650 (26") |
| BS 4504,DIN 2543-2545,EN1092 |
| Butt-Weld BW Ends | ASME B16.25 ,DIN 3239,BS 2080, EN 12627 |
| Temperature range | -29°~ 425°C |
| Design Feature |
| Construction | Lift type, Swing type,Wafer type,Pressure seal bonnet,Bolted Bonnet |
| Disc Type | Dual plate, single plate, plug type |
| Seat Sealing | Integral body seat ,seat welded and overlaid |
| Fire Safe Design | API 607,BS 6755 |
| Inspection & Test |
| Visual Inspection | MSS SP-55 |
| Material Inspection | PMI Test----Chemical Analysis |
| HB Test---Hardness Test |
| UT---Ultrasonic Test |
| RT---RadiographicTest |
| MT---Magnetic Test |
| NDT Test Non-destructive |
| Dimention inspcetion | According to drawings |
| Valve Inspection and Test | API 598,DIN 3230,EN 12266,BS 5146 |
